_Mox_
Posted 10 January 2016 - 09:51 PM
Some pics of fixing rust, i cant believe i am still on my first of 4 floor pans i have to do. Take it step by step i suppose
10 1 2016 002 (Custom).JPG 237.04K
2 downloads
10 1 2016 003 (Custom).JPG 230.16K
0 downloads
10 1 2016 004 (Custom).JPG 203.25K
0 downloads
_Mox_
Posted 10 January 2016 - 10:29 PM
I hate it when the Daisy Chains from next door park there Kia people mover in my driveway as well
I had to fit a new engine in that thing, it was a real bastard of a job never again without a hoist.
_Mox_
Posted 08 March 2016 - 09:03 PM
Finally got passenger floor pan all done and dusted
Torana paint 001 (Custom).JPG 222.57K
1 downloads
Torana paint 003 (Custom).JPG 227.13K
0 downloads
Torana paint 005 (Custom).JPG 205.71K
0 downloads
Another Holden 6 tragic
Posted 09 March 2016 - 08:58 AM
Nice job.
Not to remind you but you'll be an expert by the time you've done another three!
_Mox_
Posted 09 March 2016 - 09:55 AM
Nice job.
Not to remind you but you'll be an expert by the time you've done another three!
Yeah it is a big job, next job after this is fitting seat belts, i cant believe somebody hasn't already fitted them over the years, cant find much info on this, but i will keep looking.
Another Holden 6 tragic
Posted 09 March 2016 - 02:12 PM
_Mox_
Posted 09 March 2016 - 02:53 PM
Front seat belts have been fitted in mine, but no rears(which I would really love so I can take my young lads for a spin).
The fronts have a retractable belt mounted low on the b pillar, a nice big arse bolt through the top of the pillar to hold the top mount, then the end of the belt secures back to the lower retractor point.
The buckles simply bolt alongside the seats through reinforced holes in the floor. Don't know if it's done properly, but it works!
I have bought the big upper bolt for the b pillar off rare spares, i will probably follow how the Torana seat belt mounts are done and go from there, i will post it up as i go and get some feedback hopefully. Cheers
_Mox_
Posted 10 March 2016 - 07:40 PM
Started the drivers floor pan, this one i forgot to unbolt and move the brake line out of the way and cut through it, SHIT !!!!
Torana paint 007 (Custom).JPG 217.81K
0 downloads
Torana paint 008 (Custom).JPG 209.14K
0 downloads
Torana paint 013 (Custom).JPG 231.75K
1 downloads
Torana paint 014 (Custom).JPG 221.46K
0 downloads
_duggan208_
Posted 10 March 2016 - 10:32 PM
Almost as rusty as my HR. One of my best, roughest and the most fun car I've ever had was a black EH wagon. so I have a couple of EH stories. If you are thinking about period wheels, maybe a bit different, my wagon had a set of ROK Rockets. Had to find now. Cool EH.
Regards
_Mox_
Posted 11 March 2016 - 08:55 AM
Almost as rusty as my HR. One of my best, roughest and the most fun car I've ever had was a black EH wagon. so I have a couple of EH stories. If you are thinking about period wheels, maybe a bit different, my wagon had a set of ROK Rockets. Had to find now. Cool EH.
Regards
I had a yellow EH when i was around 19 years of age, and loved it and always wanted another one, and for the price this one had a lot of good points, it is going to be a battle to get rid of all the rust, hopefully i win in the end, i will check out those wheels to see what they look like, Cheers
Forum Member
Posted 11 March 2016 - 04:59 PM
Dragway Splats look like this if I believe
I am fairly sure they were actually named after his daughter (married name?)
She is a full tilt revhead from memory
splat.JPG 29.34K
0 downloads
_Mox_
Posted 11 March 2016 - 07:23 PM
Dragway Splats look like this if I believe
I am fairly sure they were actually named after his daughter (married name?)
She is a full tilt revhead from memory
Cheers mate i think her name was Rachael Splat by memory and a good drag racer. Would love to get my hands on a set of those.
UC's FTW!
Posted 11 March 2016 - 08:07 PM
^yep, watched her race a few times... Ominous name for a drag racer though lol
_Mox_
Posted 20 April 2016 - 07:49 PM
Things are still progressing on the floor pans very slowly, the drivers one is done, along the sill there was a quarter inch gap from the pan so i had to make up right angle section to fill the gap and it all worked well.
engine in drivers floor pan in 003 (Custom).JPG 223.75K
0 downloads
engine in drivers floor pan in 004 (Custom).JPG 240.88K
0 downloads
engine in drivers floor pan in 006 (Custom).JPG 216.27K
1 downloads
engine in drivers floor pan in 008 (Custom).JPG 177.18K
1 downloads
_Mox_
Posted 20 April 2016 - 07:52 PM
With all of this welding i think i am getting better for a gassless mig anyway, LOL
engine in drivers floor pan in 005 (Custom).JPG 213.81K
1 downloads
Edited by Mox, 20 April 2016 - 07:53 PM.
To advertise here, call 13TORANA
Posted 20 April 2016 - 08:51 PM
If that's gasless mig? Well done!!!!
_Mox_
Posted 25 April 2016 - 09:58 PM
Penetration shot for Mfr Dave
3rd floor pan 002 (Custom) (Custom).JPG 187.48K
0 downloads
CABIN ENGINE CONTROLS GALORE
Posted 25 April 2016 - 10:04 PM
look's good from here, top job Andrew.
like button for you.
Oh My, Don't you post alot
Posted 26 April 2016 - 08:12 AM
I have bought the big upper bolt for the b pillar off rare spares, i will probably follow how the Torana seat belt mounts are done and go from there, i will post it up as i go and get some feedback hopefully. Cheers
I'd go and try and buy a semi-rusty floor cut out of a HG (firewall to diff hump). A HK-HG is essentially the same floor as a HD-HR, which is a minimally modified EJ-EH. Just remove the seat belt attachment plates with captive nuts from the HG, dress them up by grinding the floor steel off the attachment face and weld them into the EH in the same positions. Any curves in the plates will be in the items from the HG. This will give you all your floor anchors, will still have to sort out the pillars and the rear uppers if you put sash belts in the rear. You'd still have to get an Engineer's report though for the points but if you are copying what GMH did I doubt they'd have too many issues.
Pops
Posted 26 April 2016 - 06:27 PM
While pulling the EH apart i found some good reading material for the garage stuffed under the drivers seat carpet
Were all of the pages stuck together
Love the EH's, dad had one but living close to the sea at Port Kembla, the rust go it
RegardSS ....Barry
UC's FTW!
Posted 26 April 2016 - 06:37 PM
OOOh, she's got her fur off!
_Mox_
Posted 26 April 2016 - 07:57 PM
I'd go and try and buy a semi-rusty floor cut out of a HG (firewall to diff hump). A HK-HG is essentially the same floor as a HD-HR, which is a minimally modified EJ-EH. Just remove the seat belt attachment plates with captive nuts from the HG, dress them up by grinding the floor steel off the attachment face and weld them into the EH in the same positions. Any curves in the plates will be in the items from the HG. This will give you all your floor anchors, will still have to sort out the pillars and the rear uppers if you put sash belts in the rear. You'd still have to get an Engineer's report though for the points but if you are copying what GMH did I doubt they'd have too many issues.
Good to know, I will have a look around, might be a bit hard to find though. Cheers Mate.
_Mox_
Posted 26 April 2016 - 08:02 PM
Were all of the pages stuck together
Love the EH's, dad had one but living close to the sea at Port Kembla, the rust go it
RegardSS ....Barry
No Barry all pages where OK, but i cant guarantee they will be when i am finished, HA HA. This EH has a lot of rust too, hope i have enough patience to bring her back to life. Cheers Mate
_Mox_
Posted 26 April 2016 - 08:08 PM
3RD floor pan progress this is as exciting as watching paint dry, which i do a lot of lately as well, LOL
engine in drivers floor pan in 010 (Custom).JPG 215.48K
0 downloads
engine in drivers floor pan in 011 (Custom).JPG 223.06K
0 downloads
engine in drivers floor pan in 012 (Custom).JPG 209.21K
0 downloads
engine in drivers floor pan in 013 (Custom).JPG 217.39K
0 downloads
Edited by Mox, 26 April 2016 - 08:11 PM.
_Mox_
Posted 26 April 2016 - 08:21 PM
I remembered to check under the floor this time before hacking with the grinder, luckily due to there being the fuel line and hand brake cable there. And it wouldn't be a proper floor pan replacement without extra rusty sections that the new section doesn't cover.
engine in drivers floor pan in 014 (Custom).JPG 192.56K
0 downloads
engine in drivers floor pan in 017 (Custom).JPG 219.77K
0 downloads
3rd floor pan 001 (Custom).JPG 184.62K
0 downloads
3rd floor pan 003 (Custom).JPG 185.35K
0 downloads
3rd floor pan 004 (Custom).JPG 211.7K
0 downloads
